High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty

Product Categories

BISPARK GROUP LIMITED

Contact Now

High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty

Name: High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty
Brand: BISPARK
Price: 245.8 USD

China High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty wholesale

Brand Name : BISPARK

Model Number : ARES

Certification : CE RoHS SAA UL DLC CB TUV NOM

Place of Origin : Guangdong,China

MOQ : negotiation

Price : 245.8-736.8 USD

Payment Terms : T/T, Western Union, PayPal, D/P, D/A

Supply Ability : 20000 PCS per Month

Delivery Time : 3-15 work days

Packaging Details : 1PC/Carton

Material : Die-casting Aluminum

Input Voltage : 90-305V/480V AC

Chip : Lumileds SMD5050

Operating Temp. : -30-45 ℃

Lumen : 60000-180000LM

Luminous Efficiency : 150LM/W

IP Rate : IP67

Life Span : 61,000 Hours

Warranty : 7 Years

Others : OEM/ODM

Contact Now

LED Sports Lighting, DIAlux for Horse riding ranch,Paddock,Opencast working,Port,High Power IP66 IP67,7 years Warranty

Inventronics / Meanwell Driver
10KV/20KV SPD lightning protector
Lumileds / Cree 5050 LED Chips
Lumen Efficacy:150LM/W
Beam Angle:15° / 30° / 60° / 90° / 140×70°
(400W 500W 600W 800W 1000W 1200W )
7 years warranty

ARES Series outdoor LED sports lighting Fixtures are designed to replace 1000W to 2500W Metal Halide and HPS lights.

Supply perfect high efficiency and UGR below 22, widely used for highways, outdoor/ indoor sport fields(Football/ baseball/ basketball/volleyball/tennis court/Hockey fields), warehouse, airport, seaport, etc. If any projects, please do not hesitate to inquiry me. Dialux simulation or IES files all can be provided. Thanks.

Item Number	NL-ARES-HM400	ARES-HM500	ARES-HM600	ARES-HM800	ARES-HM1000	ARES-HM1200
Wattage	400W	500W	600W	800W	1000W	1200W
Lumen Output	60000lm	75000lm	90000lm	120000lm	150000lm	180000lm
LED Quantity	200PCS	240pcs	280pcs	480pcs	480pcs	560pcs
Size(MM)	L435W347H211	489347211	542347211	439708211	493708211	546708211
LED Chip	Lumileds 5050
Luminous Efficacy	150LM/W
CCT	2700K-6700K
CRI	≥80Ra(2700-4000K) , ≥72Ra(4500-6700K)
Beam Angle	15° / 30° / 60° / 90° / 140×70°
IP Rating	IP67
Working Temperature	-35℃ to +55℃
Input Voltage	AC100-277V/347V/480V, 50/60Hz, ＞0.92
Warranty	7 years
Lifespan	＞50,000hrs
Material	Die-casting Aluminum housing+PC lens

High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty

1. Light source/ LED Driver of LED Sports Lighting

Lmileds chips SMD 5050 Professional optical design,
Full beam angle :A variety of light distribution meets different lighting applications. It can be get luminosity to wherever you want
Mewell or Inventronics driver

2. R&D Patented of LED Sports Lighting

Professional thermal design with Excellent Heat dissipation
The heat sink is made of AL6063-T5 aluminum material with excellent heat dissipation and corrosion resistance.

IK08 Tempered glass cover,IP67 Waterproof Structure

High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty

3. Humanized Design of LED Sports Lighting

Humanized design makes users more convenient to install.

4. Installation of LED Sports Lighting

1. Open the package and fix the bracket

2. Fix the luminaire at the bracket

3. Fix the Anti-collision net

4. Install the Anti-glare shade

5. Make sure the wiring section is insulated before installation

6. Adjust the beam angle(Finish the installation)

Product Tags:

led stadium flood lights

sports arena lighting

High Power LED Sports Light Die Casting Aluminum IP66 IP67 With 7 Years Warranty Images
